20
PERFORMANCE TEST RECORD - Agilent 6063B ELECTRONIC LOAD (Page 2 of 2)
Model Agilent 6063B Report No.____________________ Date______________________________
Test Description Minimum
Specification
Results Maximum
Specification
Measurement
Uncertainty
CONSTANT CURRENT MODE TESTS
10 Ampere Range Programming
and Readback
High Current (10A) 9.975 ____________A 10.025 4mA
Front Panel Display A
OUT
-0.022 ____________A A
OUT
+0.022 4mA
Low Current (1A) 0.9885 ____________A 1.0115
427µA
Front Panel Display A
OUT
-0.011 ____________A A
OUT
+0.011
427µA
1 Ampere Range
Programming and Readback
High Current (1A) 0.9885 ____________A 1.0115
427µA
Front Panel Display A
OUT
-0.011 ____________A A
OUT
+0.011
427µA
Low Current (0.1A) 0.0899 ____________A 1.101
56µA
Front Panel Display A
OUT
-0.010 ____________A A
OUT
+0.010
56µA
CONSTANT VOLTAGE MODE TESTS
Voltage Programming and
Readback
High Voltage (240V) 239.59 ____________V 240.408 3mV
Front Panel Display V
OUT
-0.390 ____________V V
OUT
+0.390 3mV
Low Voltage (3V) 2.876 ____________V 3.1236
35µV
Front Panel Display V
OUT
-0.153 ____________V V
OUT
+0.153
35µV
CONSTANT RESISTANCE MODE TESTS
Low Resistance Range
Resistance (24Ω)
23.6
____________Ω
24.4
Resistance (1Ω)
0.792
____________Ω
1.208
Middle Resistance Range
Resistance (500Ω)
433
____________Ω
590
Resistance (24Ω)
23.75
____________Ω
24.25
High Resistance Range
Resistance (2000Ω)
1247
____________Ω
5037
Resistance (240Ω)
223.3
____________Ω
259.5
TRANSIENT SLEW TEST
Fast Slew Transient
Slew Rate 0.083A/µs
60
____________µs
100
Slew Rate 0.0042A/µs
1.2 ____________ms 2.0
CONSTANT CURRENT PARD TEST
Current (10A) 0 __________mA 1mA RMS
