Table 5-3. Agilent 6060B/6063B Parts List - Electrical
Reference
Designation
Models Agilent Part
Number
Description
A1 6060B 06060-60024
MAIN BOARD
A1 6063B 06063-60024
MAIN BOARD
C1-8 BOTH 0160-4820
CAP-FXD 1800pF
±5% 100V
C9 BOTH 0160-5098
CAP-FXD 0.22uF
±10% 50V
C10 6060B 0160-4833
CAP-FXD 0.022uF
±10% 100V
C10 6063B 0160-2569
CAP-FXD 0.02uF
±20% 2 kV
C11-22 BOTH 0160-5422
CAP-FXD 0.047uF
±20% 50V
C23 6060B 0160-4834
CAP-FXD 0.047uF
±10% 100V
C23 6063B 0160-5422
CAP-FXD 0.047uF
±20% 50V
C24 6060B 0160-4834
CAP-FXD 0.047uF
±10% 1WV
C24 6063B 0150-0052
CAP-FXD 0.05uF
±20% 400V
C25 6060B 0160-7024
CAP-FXD 2.0uF
±10% 100V
C25 6063B 0160-7369
CAP-FXD 1uF
±10% 400V
C26 BOTH 0160-4831
CAP-FXD 4700pF
±10% 100V
C27 BOTH 0160-4835
CAP-FXD 0.1uF
±10% 50V
C28 BOTH 0160-4830
CAP-FXD 2200pF
±10% 100V
C29-32 BOTH 0160-5422
CAP-FXD 0.047uF
±20% 50V
C33 BOTH 0160-4800
CAP-FXD 120pF
±5% 100V
C34 BOTH 0160-4048
CAP-FXD 0.022
µF ±20% 0V
C35 BOTH 0160-5422
CAP-FXD 0.047
µF ±20% 50V
C36 BOTH 0160 5469
CAP-FXD 1
µF ±10% 50V
C37 BOTH 0160-4048
CAP-FXD 0.022
µF ±20% 0V
C38-44 BOTH 0160-5422
CAP-FXD 0.047
µF ±20% 50V
C45 BOTH 0160-4801
CAP-FXD 100pF
±5% 100V
C46 BOTH 0160-4831
CAP-FXD 4700pF
±10% 100V
C47,48 BOTH 0160-5422
CAP-FXD 0.047
µF ±20% 50V
C49-56 BOTH 0160-4810
CAP-FXD 330pF
±5% 100V
C57 BOTH 0160-4835
CAP-FXD 0.1
µF ±10% 50V
C58 BOTH 0160-4833
CAP-FXD 0.022
µF ±10% 100V
C59 BOTH 0160-4831
CAP-FXD 4700pF
±10% 100V
C60 BOTH 0160-5422
CAP-FXD 0.047
µF ±20% 50V
C61 BOTH 0160-4832
CAP-FXD 0.01
µF ±10% 100V
C65 BOTH 0160-4833
CAP-FXD 0.022
µF ±10% 100V
C66 6060B 0160-4833
CAP-FXD 0.022
µF ±10% 100V
C66 6063B 0160-5166
CAP-FXD 0.015
µF ±20% 100V
C67 BOTH 0160-4833
CAP-FXD 0.022
µF ±10% 100V
C68 6060B 0160-4835
CAP-FXD 0.1
µF ±10% 50V
C69 BOTH 0160-4832
CAP-FXD 0.01
µF ±10% 100V
C70 BOTH 0160-5349
CAP-FXD 200pF
±5% 100V
C71 6060B 0160-4805
CAP-FXD 47pF
±5% 100V
C71 6063B 0160-4807
CAP-FXD 33pF
±5% 100V
C72 6060B 0160-4787
CAP-FXD 22pF
±5% 100V
C72 6063B 0160-4807
CAP-FXD 33pF
±5% 100V
C73 6060B 0160-4787
CAP-FXD 22pF
±5% 100V
C73 6063B 0160-4807
CAP-FXD 33pF
±5% 100V
C74 6060B 0160-4787
CAP-FXD 22pF
±5% 100V
C74 6063B 0160-4807
CAP-FXD 33pF
±5% 100V
