Agilent Technologies 81110A - The Levels Screen

82
Using the 81110A/81104A
T
TT
The
he he
he T
TT
Ti
ii
im
mm
mi
ii
in
nn
ng
g g
g S
SS
Sc
cc
cr
rr
ree
eeee
een
nn
n
 L
EAD
E
D
%
The absolute transition time expressed as a percentage of pulse
width. In this format if you adjust the pulse width, the transition time
is adjusted to maintain the edge-time as a percentage of the width.
N
NN
NO
OO
OTE
TETE
TE You cannot have the width format set to D
TY
C
YC
and the leading/trailing
edge format set to percentage of width (L
EAD
ED%/T
RAIL
E%) at the same
time.
N
NN
NO
OO
OTE
TETE
TE The leading edge of an Agilent 81110A with Agilent 81112A 3.8 V/330 MHz
outputs can be selected from 0.8 ns or 1.6 ns.
Pulse Trailing Edge Parameter
Set the trailing-edge transition time of the pulse, measured from 10% to
90% of pulse amplitude.
There are three formats available, selectable in text mode:
 =L
EAD
E
The trailing-edge transition time is coupled directly to the leading
edge to maintain a symmetrical pulse.
 T
RAIL
E
D
The absolute transition time measured from 10% to 90% of pulse
amplitude. In this format the trailing edge is independent of the
leading edge and pulse width.
 T
RAIL
E%
The trailing-edge transition time expressed as a percentage of the
pulse width. In this format if you adjust the pulse width, the transition
time is adjusted to maintain the edge-time as a percentage of the
width.
N
NN
NO
OO
OTE
TETE
TE Note that you cannot have the width format set to D
TY
C
YC
and the
leading/trailing edge format set to percentage of width (L
EAD
E
D
%/
T
RAIL
E%) at the same time.
N
NN
NO
OO
OTE
TETE
TE The trailing edge of the Agilent 81110A with Agilent 81112A 3.8 V/
330 MHz outputs is always coupled to the leading edge.
