508 Chapter12
Replaceable Parts
Standard-Value Replacement Components
A41 RS-232 and Parallel Interface Board
All 8590 E-Series and L-Series spectrum analyzers
and 8591C cable TV analyzers and 8594Q QAM
analyzers (Option 043)
08590-60366
A41A1 RS-232 and Parallel Interface Connector
All 8590 E-Series and L-Series spectrum analyzers
and 8591C cable TV analyzers and 8594Q QAM
analyzers (Option 043)
1 08590-60369
A41/A43 Dual I/O Board
8591C, 8591E, 8593E, 8594E, 8594L, 8594Q,
8595E, and 8596E (Option 041 or Option 043)
08590-60366
A101 Fast ADC Board
8591C, or 8591E, 8593E, 8594E, 8595E, and 8596E
(Option 101)
4 5062-7079
A102 Demod/TV-Sync Board
8591C, or 8591E, 8593E, 8594E, 8595E, and 8596E
(Option 102)
6 5062-1982
A103 Demod/QPD Board
8591E, 8593E, 8594E, 8595E, and 8596E (Option 103)
7 5062-1983
A105 Gated Video Board
8591C, or 8591E, 8593E, 8594E, 8595E, and 8596E
(Option 105)
2 5062-7754
A110 CELLULAR DEMOD/TV
8591E, 8593E, 8594E, 8595E, and 8596E (Option 110)
1 5063-0234
A111 Event Control Board
8593E (Options E02, E04)
7 5063-0214
A119 Noise Card Board
8591C, 8591E, 8593E, 8594E, 8595E, and 8596E
(Option 119)
3 5062-8258
A130 Narrow Bandwidth Board
8591C, 8591E, 8593E, 8594E, 8595E, and 8596E
(Option 130)
7 08590-60352
Table 12-5 Assembly-Level Replaceable Parts (Continued)
Reference
Designator
Description CD Part
Number
To Next Page
