Chapter 12 509
Replaceable Parts
Standard-Value Replacement Components
A151 Down Converter Assembly
8591E, 8593E, 8594E, 8595E, and 8596E (Option 151)
5062-8246
A160 DSP Assembly
8591E, 8593E, 8594E, 8595E, and 8596E (Option 160)
without firmware
8591E, 8593E, 8594E, 8595E, and 8596E (Option 160)
with firmware
5062-8245
08591-60101
A163 DSP Assembly (GSM/DCS Formats)
8591E, 8593E, 8594E, 8595E, and 8596E (Option 163)
with firmware
5062-0577
A190A1 Downconverter (RF) Assembly
8594Q (Option 190)
08594-60052
A190A2 Demod Assembly
8594Q (Option 190)
08594-60084
A190A3 DSP
8594Q (Option 190)
08594-60051
AT1 Isolator (2 to 4 GHz)
8591C only
10 dB Attenuator
8592L, 8593E, 8594E, 8594L, 8594Q, 8595E,
and 8596E
0960-0084
0955-0122
AT2 50 Ohm Termination
8590L and 8591E
8593E, 8594E, 8595E, and 8596E
9 0960-0053
3 1250-2289
B1 Fan (includes cable assembly)
All 8590 E-Series and L-Series spectrum
analyzers, 8591C cable TV analyzers, and 8594Q QAM
analyzers
2 5063-0243
F1 Fuse 5.0 A 250 V F
All 8590 E-Series and L-Series spectrum analyzers,
8591C cable TV analyzers, and 8594Q QAM analyzers
3 2110-0709
Table 12-5 Assembly-Level Replaceable Parts (Continued)
Reference
Designator
Description CD Part
Number
