510 Chapter12
Replaceable Parts
Standard-Value Replacement Components
FL1 Low-Pass Filter 4.4 GHz
8592L, 8593E, 8594E, 8594L, 8594Q, 8595E,
and 8596E
1 0955-0519
Low-Pass Filter 4.9 GHz
8590L, 8591C, and 8591E
2 9135-0048
J1 Input 50 Ω
8590L, 8591E, 8594E, 8594L, and 8594Q
8592L, 8593E, 8595E, and 8596E
8592L and 8593E Option 026
8592L and 8593E Option 027
6 1250-2191
1250-2180
08673-60040
5063-0230
Input 75 Ω (MLA)
8591C
8590L, and 8591E (Option 001)
0955-1005
0955-1005
J3 RF OUT 50 Ω
8590L and 8591E Option 010
8593E, 8594E, 8594Q, 8595E, and 8596E Option 010
1250-2191
1250-2191
TG-RF OUT 50 Ω
8593E Option 026
5061-5311
RF OUT 75 Ω (MLA)
8590L, 8591C, and 8591E Option 011
0955-1005
Table 12-5 Assembly-Level Replaceable Parts (Continued)
Reference
Designator
Description CD Part
Number
