Chapter 12 511
Replaceable Parts
Standard-Value Replacement Components
Table 12-6 Replaceable Cables
Reference
Designator
Description CD Part Number
W1 CABLE ASSY WITH LINE SWITCH, A1 TO A16J9
All 8590 Series analyzers
2 5062-4809
W2 CABLE ASSY, DISPLAY VIDEO, A2 TO A16J8
All 8590 -Series analyzers
7 5063-0602
W3 CABLE ASSY, INTENSITY, WITHOUT
POTENTIOMETER, A1R1 TO A2
All 8590 Series analyzers 4 08590-60037
W4 CABLE ASSY, KEYBOARD, A1A1J1 TO A16J10
All 8590 Series analyzers
6 08592-60037
W5 CABLE ASSY, PROBE POWER, WITH FILTER,
WITHOUT CONNECTOR, A1A1 TO A1
All 8590 Series analyzers
3 8120-8152
W6 JUMPER, 10 MHz REF OUTPUT TO EXT REF IN
All 8590 Series analyzers
5 1250-1499
W7 CABLE ASSY, CAL OUTPUT, A9J2 TO A1
8590L, 8591C, and 8591E (75 Ω)
8590L, 8592L, 8591E, 8593E,
8594E, 8594L, 8594Q, 8595E, and 8596E (50 Ω)
3 08590-60028
6 8120-5052
W8 CABLE ASSY, 600 MHz DRVR, A9J5 TO A3A4J4
8592L, 8593E, 8594E, 8594Q,
8595E, and 8596E
8 8120-5020
CABLE ASSY, 600 MHz DRVR, A9J5 TO A5J5
8590L, 8591C, and 8591E
8 8120-5020
W9 CABLE ASSY, 2ND IF, A5J2 TO A9J4
8590L, 8591C, and 8591E
1 8120-5023
CABLE ASSY, 2ND IF, A3A9J2 TO A9J4
8592L, 8593E, 8594E, 8594L,
8594Q, 8595E, and 8596E
1 8120-5106
