Agilent Technologies 8719ES Programmer's Guide

Appendix A A-11
Preset Conditions
Preset State
Table A-8 Time Domain Conditions (Option 010 only)
Preset Conditions Preset Value
Transform Off
Transform Type Bandpass
Start Transform:
8720 E series analyzers −1 nanoseconds
8753ET/ES analyzers −20 nanoseconds
Transform Span:
8720 E series analyzers 4 nanoseconds
8753ET/ES analyzers 40 nanoseconds
Gating Off
Gate Shape Normal
Gate Span:
8720 E series analyzers 500 picoseconds
8753ET/ES analyzers 20 nanoseconds
Gate Start:
8720 E series analyzers −500 picoseconds
8753ET/ES analyzers −10 nanoseconds
Demodulation Off
Window Normal
Use Memory Off
Table A-9 System Conditions
Preset Conditions Preset Value
GPIB Addresses Last Active State
GPIB Mode Last Active State
Focus Last Active State
Clock Time Stamp On
Preset: Factory/User Last Selected State
