Agilent 85038 Family of Calibration Kits
The 85038A calibration kit contains open circuits,
short circuits, and terminations with both male
and female 7-16 connectors. More economical ver-
sions of this kit are available: the 85038M contains
only male devices, and the 85038F provides only
female devices (see following table). Each kit con-
tains a floppy disk with the calibration kit defini-
tion for use with 8712, 8714, 8753, 8719, 8720,
8722, and 8510C network analyzers.
Contents of 7-16 Calibration Kits
Description Part Number 85038A 85038M 85038F
Open circuit, female 85038-80002 X X
Open circuit, male 85038-80003 X X
Short circuit, female 85038-80004 X X
Short circuit, male 85038-80005 X X
Termination, female 85038-80006 X X
Termination, male 85038-80007 X X
7-16 adapter, 11906-80016 X
female-to-female
7-16 adapter, 11906-80015 X
male-to-male
Calibration kit data disk 85038-10001 X X X
Torque wrench 8710-2175 X
Open-end wrench 8710-2174 X
Specifications
Frequency coverage dc to 7.5 GHz
(usable to 8 GHz)
Nominal impedance 50 ohms
Open circuits Reflection phase
±1 degree from nominal
Short circuits Reflection phase
±1 degree from nominal
Terminations Return loss >40 dB
7-16 to 7-16 adapters Return loss >40 dB
(VSWR <1.02)
7-16 to 50 ohm type-N Return loss >36 dB
adapters (VSWR <1.03)
7-16 to 7-mm adapters Return loss >38 dB
(VSWR <1.025)
7-16 to 3.5-mm adapters Return loss >34 dB
(VSWR <1.04)
Agilent 11906 Family of Adapter Kits
The 11906 family consists of four adapter kits:
11906A 7-16 to 7-16 adapter kit
Description Quantity Part number
7-16 male-to-male adapter 1 11906-80015
7-16 female-to-female adapter 1 11906-80016
7-16 male-to-female adapter 2 11906-80017
11906B 7-16 to 50-ohm type-N adapter kit
Description Quantity Part number
Type-N male to 7-16 male 1 11906-80007
adapter
Type-N female to 7-16 female 1 11906-80008
adapter
Type-N female to 7-16 male 1 11906-80009
adapter
Type-N male to7-16 female 1 11906-80010
adapter
11906C 7-16 to 7-mm adapter kit
Description Quantity Part number
7-mm to 7-16 male adapter 2 11906-80012
7-mm to 7-16 female adapter 2 11906-80013
11906D 7-16 to 3.5-mm adapter kit
Description Quantity Part number
3.5-mm male to 7-16 male 1 11906-80002
adapter
3.5-mm male to 7-16 female 1 11906-80005
adapter
3.5-mm female to 7-16 male 1 11906-80004
adapter
3.5-mm female to 7-16 female 1 11906-80003
adapter
85039B type-F calibration kit
Contains a set of 75-ohm type-F standards to cali-
brate the 8753ES with a 75-ohm test set for the
measurement of devices with type-F connectors.
Description Part number
F-male 75-ohm termination 85039-60007
F-female 75-ohm termination 85039-60004
Specifications for termination:
DC to 1 GHz RL ≥ 45 dB
1 to 3 GHz RL ≥ 38 dB
F-male 75-ohm short 85039-60008
F-female 75-ohm short 85039-60003
F-male 75-ohm open 85039-60009
F-female 75-ohm open 85039-60005
F-female to F-female 85039-60002
75-ohm adapter
F-male to F-male 75-ohm adapter 85039-60006
Typical type-F adapter characteristics:
DC to 1 GHz RL ≥ 40 dB
1 to 3 GHz RL ≥ 32 dB
F-female to N-male 85039-60013
75-ohm adapter
F-male to N-female 85039-60011
75-ohm adapter
Typical type-F to type-N adapter characteristics:
DC to 1 GHz RL ≥ 38 dB
1 to 3 GHz RL ≥ 32 dB
