Agilent Technologies 8753ES Service Guide

Chapter 2 2-145
System Verification and Performance Tests
Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Report Number
Option(s) Date
4. Test Port Output Power Linearity
Frequency Range: 300 kHz to 3 GHz
Power Setting
dBm
Marker 1
Maximum (dB)
Marker 2
Minimum (dB)
Specification
(dB)
Meas.
Uncert.
(dB)
−15 ± 0.2 ± 0.04
−13 ± 0.2 ± 0.03
−11 ± 0.2 ± 0.03
−9 ± 0.2 ± 0.03
−7 ± 0.2 ± 0.03
−5 ± 0.2 ± 0.03
−3 ± 0.2 ± 0.02
−1 ± 0.2 ± 0.02
+1 ± 0.2 ± 0.02
+3 ± 0.2 ± 0.02
+5 ± 0.2 ± 0.03
+7 ± 0.5 ± 0.03
+8 ± 0.5 ± 0.03
+9 ± 0.5 ± 0.03
+10 ± 0.5 ± 0.03
