Agilent Technologies E4421B Configuration Guide

4
Hardware options Requires Not compatible with
High-stability timebase x Standard x Standard
❑ Option 1E5
High power with mechanical attenuator x x x x Options UNA, 300,
❑ Option UNB (Retrofit =Special
5
) H03, H98, H99
Alternate time slot level control x x Option UN8 Option UNB, H03,
❑ Option UNA (Retrofit =Special
5
) H98, H99
Improved ACP performance for TETRA, x x Option UNB, UNA, H03
CDMA, WCDMA and cdma2000
❑ Option H99 (Retrofit =Special
5
)
High-performance pulse modulation x x
❑ Option 1E6
Internal dual arbitrary waveform generator x x Options 300, H03, H98
❑ Option UND (Retrofit =004
2
)
Real-time I/Q baseband generator 1M RAM x x Options H03, H98
❑ Option UN8 (Retrofit =008
2
)
Add 7M RAM to Option UN8 x x Option UN8 Options H03, H98
❑ Option UN9 (Retrofit =009
2,6
)
Internal bit error rate (BER) analyzer x x Option UN8 Options H03, H98, 300
❑ Option UN7 (Retrofit =007
2
) (or UN3 or UN4)
Firmware options
Multicarrier, multichannel cdmaOne x x Option UND Options 300, H03, H98
personality for Option UND
❑ Option UN5 (Retrofit =005
3
)
Multicarrier, multichannel W-CDMA x x Option UND Options 300, H03, H98
personality for Option UND
❑ Option 100 (Retrofit =150
3
)
Multicarrier, multichannel cdma2000 x x Option UND Options 300, H03, H98
personality for Option UND
❑ Option 101 (Retrofit =151
3
)
Real-time 3GPP W-CDMA personality for x x Option UN8, revision C Options H03, H98
Option UN8
❑ Option 200 (Retrofit=250
3,4
)
Real-time cdma2000 personality for Option UN8 x x Option UN8, revision C Options H03, H98
❑ Option 201 (Retrofit =251
3,4
)
Real-time EDGE personality for Option UN8 x x Option UN8, revision C Options H03, H98
❑ Option 202 (Retrofit =252
3,4
)
Base station BERT
1
x Option UN8, revision C, Options UNB, H99, UND,
❑ Option 300 202; recommend UNA. UN5, 100, 101, H98, H03,
Also requires E4406A UN7
with options 300 and 202
ESG-A series ESG-AP series ESG-D series ESG-DP series
1. Currently for GSM/EDGE only. Also refer to GSM/EDGE Base Station Test, literature number 5968-8333E.
2. This customer-installable upgrade kit includes the necessary hardware and instructions for option installation in any digital B model, excluding instruments
with Option 1EM. Depending on the existing option configuration, the kit may include hardware that will be discarded.
3. Customer installable with software license key.
4. This upgrade requires Option UN8 revision C. A hardware upgrade may be required for retrofits. Contact Agilent Technologies for more details.
5. This special requires installation at the Agilent Technologies factory. Contact your Agilent Technologies sales representative for more information.
6. The Option 009 retrofit kit includes both Option UN8 and Option UN9.
Note: Options UND, UN5, UN7, UN8, 100, 101, 200, 201, and 202 are mutually compatible and can be loaded in the same instrument.
Choosing options for a new purchase or a retrofit
Option availability and compatibility
