Installation Note E4400-90214 5
Upgrade Kit E4400-60166 Contents
Item
Quantity
Description
Part
Number
Std (No
Opt’s
a
)
a Implies no other digital hardware installed.
UN7
1 1 0 This installation note E4400-90214
2 1 1 Dual arbitrary waveform generator board E4400-60187
3 1 0 Rear-panel interface board E4400-60145
4 1 0 Rear panel (Option UND) E4400-00031
5 1 0 W3, DATA to motherboard or
DATA to Data Generator (A8J2) (Option UN3/4 or UN8/9)
8120-5063
6 1 0 W4, DATA CLOCK to motherboard or
DATA CLOCK to Data Generator (A8J1) (Option UN3/4 or UN8/9)
8120-5063
7 1 0 W5, SYMBOL SYNC to motherboard or
SYMBOL SYNC to Data Generator (A8J3) (Option UN3/4 or UN8/9)
8120-5063
8 1 0 W15, dual arbitrary waveform generator (A5J3) to BASEBAND
GEN REF IN (13 MHz)
8120-5055
9 1 0 W16, dual arbitrary waveform generator (A5J2) to Q OUT 8120-5055
10 1 0 W17, dual arbitrary waveform generator (A5J1) to I OUT 8120-5055
11 1 0 W18, rear-panel interface board (A17) to dual arbitrary waveform
generator (A5P1) ribbon cable
8120-8458
12 1 1 W24, for future use with Options UND and UN3/4 or
Options UND and UN8/9
E4400-20131
13 11 0 Washer, lock 0.4721D 2190-0102
14 3 0 Washer, lock 0.4091D 3050-1919
15 14 0 Nut, hex 15/32-32 2950-0035
16 3 0 Plug, hole 0.500D 6960-0002
17 1 0 Label, Option UND serial number 7120-1232
18 1 0 Label, front-panel overlay-connectors (Option UND) E4400-80006
19 1 0 Safety solvent cleaner 8500-6269
20 1 0 Firmware Upgrade Kit E4400-60230
21 1 0 W25, INT Q coax cable A14P103 to Daughter board A15J8 8120-8748
22 1 0 W26, INT I coax cable A14P102 to Daughter board A15J9 8120-8748
23
b
b For ESG-DP Models E4434B, E4435B, E4436B and E4437B.
1 0 W25, INT Q coax cable A14P103 to Daughter board A15J8 8120-8781
24
b
1
0 W26, INT I coax cable A14P102 to Daughter board A15J9 8120-8781
