Preparing for Use ESG Family Signal Generators
Installing the Signal Generator
1-4
User’s Guide
Ventilation
CAUTION Ventilation Requirements: When installing the product in a cabinet, the
convection into and out of the product must not be restricted. The ambient
temperature (outside the cabinet) must be less than the maximum operating
temperature of the product by 4
°
C for every 100 watts dissipated in the
cabinet. If the total power dissipated in the cabinet is greater than 800 watts,
then forced convection must be used.
Cooling holes are located on the sides and bottom of the instrument cover and the rear
panel of the instrument. Do not allow these holes to be obstructed as they allow air flow
through the signal generator.
Environment
This product is designed for use in the following environmental conditions:
• indoor use
• < 15,000 feet (4,572 meters) altitude
• 0 to 55
°
C temperature, unless specified differently
• maximum relative humidity 80% for temperatures up to 31
°
C, decreasing linearly to
50% relative humidity at 40
°
C
CAUTION This product is designed for use in INSTALLATION CATEGORY II and
POLLUTION DEGREE 2, per IEC 1010 and 664 respectively.
Proper Usage and Cleaning
The signal generator protects against finger access to hazardous parts within the
enclosure, but does not protect against the ingress of water.
WARNING If this product is not used as specified, the protection provided by
the equipment could be impaired. This product must be used in a
normal condition only (in which all means for protection are intact).
WARNING To prevent electrical shock, disconnect the signal generator from
mains before cleaning. Use a dry cloth or one slightly dampened with
water to clean the external case parts. Do not attempt to clean
internally.
