Serial Number Prefixes:
User’s Guide
Agilen
t T
echnol
ogies
ESG F
amily Signal Generators
P
art
No.
E4400-
90323
Printed in USA
Apri
l 2002
© Copyrig
ht 1999-20
02 Agi
lent T
echnologies, Inc.
(Affix Labe
l Here)
1
3
Table of Contents
Default Chapter
5
Table of Contents
5
1 Preparing for Use
7
Installing the Signal Generator
8
Meeting Electrical and Environmental Requirements
9
Verifying Signal Generator Operation
13
See Agilent Technologies ESG Family Internet Page for the Latest Information
16
2 Using Functions
17
Setting Frequency and Power Levels
18
Setting up Internally Generated Amplitude Modulation
21
Setting up Internally Generated Frequency Modulation
23
Creating a Step Sweep and a List Sweep
25
Saving and Recalling an Instrument State
28
Enabling Options
29
Enabling a Software Option
31
If You Encounter a Problem
32
No Modulation at the Rf Output
33
The Power Supply Has Shut down
33
Incorrect List Sweep Dwell Time
34
Returning a Signal Generator to Agilent Technologies
36
Agilent Technologies Sales and Service Offices
37
3 Front and Rear Panel
39
Front Panel Overview
40
Display Annotation
46
Rear Panel Overview
50
4 Hardkey and Softkey Reference
59
Ampl
71
Amplitude
77
Arrow Keys
78
Display Contrast Keys
79
Freq
92
Frequency
96
Help
97
Hold
98
Incr Set
99
I/Q
100
LF out
109
Local
121
Mod On/Off
122
Mode
123
Numeric Keypad
124
Phase Modulation
125
Power Switch
138
Preset
139
Pulse
140
Recall
144
Return
147
RF On/Off
148
Save
149
Sweep/List
154
Trigger
167
Utility
169
Gpib Address
180
5 Memory Structure
199
Memory Types
200
File Storage - the Memory Catalog
201
6 Safety and Regulatory
203
Safety Notes
204
Instrument Markings
205
General Safety Considerations
206
Statement of Compliance
207
Assistance
208
Certification
209
Declaration of Conformity
210
Compliance with German Noise Requirements
211
