Installation Guide 17
E444xAU IF Output Options E444xAU Options H20, H25 and H70
Installation Procedure
Figure 15 Top View Cable Orientation without Option H7L or HNQ
This concludes the installation of the E444xAU that do not include Options H7L or HNQ.
Front
321.4 MHz Out
321.4 MHz IF In
321.4 MHz IF Out
Option IF Out
321.4 MHz IF Out
Option IF Out
3rd Converter Board
Option IF Board
Option IF Out Cable
321.4 MHz IF Out
Cable
E4440-60412
W52
E4440-60395
W41
