4 Installation Note E4440-90597
Option BAB Hardware Retrofit Kit
Contents
Tools Required
❏ T-20 Torx driver
❏ T-10 Torx driver
❏ 5/16-inch open end wrench
❏ Calibration software. Latest software information and downloads available at
http://www.agilent.com/find/calibrationsoftware
❏ Test equipment supported by the calibration software.
❏ PSA Series Spectrum Analyzer and Service Guide. This manual is available as part of
the E4440AU, E4443AU, or E4445AU Option OBW kits.
❏ Microsoft Windows based personnel computer
❏ Windows XP Professional, Windows 2000
Quantity
Description Agilent Part
Number
1 Option Upgrade Entitlement Certificate ---
1 Installation Note this note
2
Screws, M3x0.5 8mm-LG
(Crest Washer-Pan Head-TORX)
0515-0372
1 APC 3.5 Input Connector Assembly
The input connector assembly is made up of:
W7, Input Cable semi-rigid
Input connector, APC 3.5
Bracket, APC 3.5
Nut, connector mounting
E4440-60335
