Installation Guide 13
E444xAU IF Output Options E444xAU Options H20, H25 and H70
Installation Procedure
Figure 11 Option IF Board Connector Layout
Figure 12 Top View of the PSA Instrument
J5 321.4 MHz IF OUT J1 321.4 MHz IF IN J2 IF Out
Guide Slot (front panel)
321.4 IF Connector 3rd Converter bd. Guide Slot (rear panel)
from the 3rd Converter bd.
Option Slot 2
