20 Installation Guide
E444xAU Options H20, H25 and H70 E444xAU IF Output Options
Performance Tests and Adjustments
Equipment Required
Gather the equipment listed in the Tables below to verify the performance of the PSA
amplitude at the Option IF Output on the rear panel.
Table 5 Signal Source Equipment
Description Characteristics Model
Synthesized
Sweeper
Frequency: Must sweep 100 MHz around 1 GHz
Amplitude: >0 dBm
83620B
Table 6 Analyzer Equipment (test spectrum analyzer)
Description Characteristics Model
Spectrum
Analyzer
Upper Frequency Range: 2 GHz 8562E
8563E
Table 7 Power Meter Equipment
Description Characteristics Model
Power Meter Absolute Accuracy: ± 0.5%
Resolution: 0.01 dB
Reference Accuracy: 1.2% Power
Reference Accuracy: ± 0.9%
Compatible with Agilent 8480 series power sensors
dB relative mode
E4419B
E4418A
Power Sensor Frequency Range: 1 MHz to 4.0 GHz
SWR at 50 MHz: ≤ 1.05
1 MHz to 4 GHz SWR: ≤ 1.22:1
Type-N (m) 50 Ω
8482A
8481A
Table 8 Cables
Description Characteristics Agilent
Part Numbers
APC 3.5 (m)(m)
2 required
DC to 26.5 GHz
Length: ≤ 92 cm (36 in)
Insertion Loss: ~2 dB
8120-4921
SMA Low-loss, 1 m 5064-5458
