26 Chapter 2
Front and Rear Panel Features
Front Panel Overview
Display Annotations
Ite
m
Description Associated Function Keys
1
Detector type
a
Det/Demod, Detector
2 Reference level Amplitude, Ref Level
3 Active function block Refer to the description of the activated function.
4 Screen title
Display, Title
5 Time and date display System, Time/Date
6
RF attenuation
a
Amplitude, Attenuation
7 Display line Display, Display Line
8Marker Marker
9 Active marker with frequency and amplitude
displayed
Marker
