136 Chapter 3
Programming the Status Register System
Status Groups
Data Questionable Condition Register
The Data Questionable Condition Register continuously monitors the hardware and firmware status of the
signal generator; condition registers are read only.
Table 3-7 Data Questionable Condition Register Bits
Bit Description
0, 1, 2 Unused. These bits are always set to 0.
3 Power (summary). This is a summary bit taken from the QUEStionable:POWer register. A 1 in this bit
position indicates that one of the following may have happened: the ALC (Automatic Leveling
Control) is unable to maintain a leveled RF output power (i.e., ALC is UNLEVELED), the reverse
power protection circuit has been tripped. See the “Data Questionable Power Status Group” on
page 138 for more information.
4 Temperature (OVEN COLD). A 1 in this bit position indicates that the internal reference oscillator
(reference oven) is cold.
5
Frequency (summary). This is a summary bit taken from the QUEStionable:FREQuency register. A 1
in this bit position indicates that one of the following may have happened: synthesizer PLL unlocked,
10 MHz reference VCO PLL unlocked, 1 GHz reference unlocked, sampler, YO loop unlocked or
baseband 1 unlocked. For more information, see the “Data Questionable Frequency Status Group” on
page 141.
6 Unused. This bit is always set to 0.
7 Modulation (summary). This is a summary bit taken from the QUEStionable:MODulation register. A
1 in this bit position indicates that one of the following may have happened: modulation source 1
underrange, modulation source 1 overrange, modulation source 2 underrange, modulation source 2
overrange, modulation uncalibrated. See the “Data Questionable Modulation Status Group” on
page 144 for more information.
8 Calibration (summary). This is a summary bit taken from the QUEStionable:CALibration register. A
1 in this bit position indicates that one of the following may have happened: an error has occurred in
the DCFM/DCΦM zero calibration, an error has occurred in the I/Q calibration. See the “Data
Questionable Calibration Status Group” on page 147 for more information.
9 Self Test. A 1 in this bit position indicates that a self-test has failed during power-up. This bit can only
be cleared by cycling the signal generator’s line power. *CLS will not clear this bit.
10–14 Unused. These bits are always set to 0.
15 Always 0.
