Agilent Technologies E8363C Service Note

Page 3 of 5 E8363C-02A
9. Loosen the two screws on the inverter shield shown in Figure 2, using a T-10 wrench.
Figure 2
10. Remove the two screws from the PCB shown in Figure 3, using a T-10 wrench.
Disconnect the three cables connected to the PCB.
Figure 3
Remove the three cables from
the PCB
Remove the two screws
from the PCB
With T-10 wrench
