Agilent Technologies EasyEXPERT

Supported Analyzer and Required Equipment
Each test definition (Library) supports the following analyzer, and requires the following
accessories, modules, and/or equipment.
Category Test definition name Supported analyzer Required equipment and quantity
BJT BC Diode Fwd B1500A,4155B/C,4156B/C SMU 2
BC Diode Rev B1500A,4155B/C,4156B/C SMU 2
BVcbo B1500A,4155B/C,4156B/C SMU 2
BVcei B1500A,4155B/C,4156B/C SMU 3
BVceo B1500A,4155B/C,4156B/C SMU 2
BVebo B1500A,4155B/C,4156B/C SMU 2
CS Diode Fwd B1500A,4155B/C,4156B/C SMU 2
CS Diode Rev B1500A,4155B/C,4156B/C SMU 2
Ctc-Freq Log B1500A MFCMU 1
Ctc-Vc B1500A MFCMU 1
Cte-Ve B1500A MFCMU 1
Cts B1500A MFCMU 1
EB Diode Fwd B1500A,4155B/C,4156B/C SMU 2
EB Diode Rev B1500A,4155B/C,4156B/C SMU 2
G-Plot ConstVce Pulse B1500A,4155B/C,4156B/C SMU 4
G-Plot ConstVce Pulse[3] B1500A,4155B/C,4156B/C SMU 3
G-Plot ConstVce B1500A,4155B/C,4156B/C SMU 4
G-Plot ConstVce[3] B1500A,4155B/C,4156B/C SMU 3
G-Plot Vbc=0V Pulse B1500A,4155B/C,4156B/C SMU 4
G-Plot Vbc=0V Pulse[3] B1500A,4155B/C,4156B/C SMU 3
G-Plot Vbc=0V B1500A,4155B/C,4156B/C SMU 4
G-Plot Vbc=0V[3] B1500A,4155B/C,4156B/C SMU 3
hfe-Vbe ConstVce B1500A,4155B/C,4156B/C SMU 4
hfe-Vbe Vbc=0V B1500A,4155B/C,4156B/C SMU 4
Ic-Vc Ib B1500A,4155B/C,4156B/C SMU 4
Ic-Vc Ib[3] B1500A,4155B/C,4156B/C SMU 3
Ic-Vc Pulse Ib B1500A,4155B/C,4156B/C SMU 4
Ic-Vc Pulse Ib[3] B1500A,4155B/C,4156B/C SMU 3
Ic-Vc Pulse Vb B1500A,4155B/C,4156B/C SMU 4
Ic-Vc Pulse Vb[3] B1500A,4155B/C,4156B/C SMU 3
