E440xBU Option H70 Performance Test
Table 4 50 Ω Adapters
Description Characteristics Model Number/
Part Number
Adapter, 3.5 (f) to 3.5 (f)
Two required
VSWR: ≤ 1.05:1 83059B
BNC to dual banana 1251-0781
BNC Tee (f, m, f) 1250-0781
BNC (m) to SMA (f) VSWR: ≤ 1.13:1 1250-1700
BNC (f) to SMA (m) 1250-1200
Type N (m) to 3.5 mm (m) VSWR: ≤ 1.08:1 1250-1743
Type N (m) to APC 3.5 (f)
(two required)
VSWR: ≤ 1.08:1 1250-1744
Type N (f) to APC 3.5 (f) For the 83620B
VSWR: 1.08:1
1250-1745
APC 3.5 (m) to APC 3. 5 (m)
(two required)
VSWR: ≤ 1.12:1 1250-1748
APC 3.5 (f) to APC 3.5 (f) Connector saver for 83630B
VSWR: 1.15:1
1250-1749
Type N (f) to APC 3.5 (m)
(two required)
VSWR: 1.08:1 1250-1750
Type N (f) to N (f) VSWR: 1.03:1 ≤ 1.3 GHz
~1.15 ≤ 18 GHz
1250-1472
Type N (m) to BNC (m) 1250-1473
Type N (m) to N (m) VSWR: 1.03:1 ≤ 1.3 GHz
~1.15 ≤ 18 GHz
1250-1475
Type N (m) to BNC (f) VSWR: ≤ 1.03:1 ≤ 1.3 GHz
~1.15 ≤ 18 GHz
1250-1476
Type N (f) to BNC (m) VSWR: 1.03:1 ≤ 1.3 GHz
~1.15 ≤ 18 GHz
1250-1477
