Agio 98900L - Natural Gas Conversion; Disconnecting Gas Lines; Orifice Replacement and Reconnection; Leak Checking and Labeling

8
Natural gas conversion must be performed only by natural gas provider or service company.
1. Disconnect the gas hose from the gas valve. See Fig. 13.
Figure
13
2. Disconnect the gas tube from the orifice and remove the orifice holder as shown in Fig .14.
Figure
14
3. Replace the propane orifice (See Figure 15) with the natural gas orifice from the kit and reinstall
the orifice holder by tightening the nuts as shown in Fig. 16. Reconnect and tighten the gas tube to
the orifice.
Figure
15
Figure 1
6
Apply a solution of soapy water to all connections to check for leaks. If soap bubbles continue to form,
the connection has a leak. If a leak is found, close the tank valve and tighten all connections.
NEVER USE A FLAME TO CHECK FOR LEAKS.
Stick the conversion label on the rating plate as shown in Fig. 17.
