Agora Models Bismarck - Page 41

Completed work
The mainmast and four heavy anti-aircraft guns
have been fitted to the aft superstructure.
01
05
03
12505
12505
12506
12507
12505
12505
02
04
Take a double barrel 125-06 and fit it into one of
the mounts 125-05 from below. The side pins on
the barrels fit in the semicircular recesses on the
mount (arrows).
Separate a base plate 125-07 from one of the two
frames. Apply a little superglue to the recess around
the lower edge of the gun mount 125-05 and fix the
base to the mount, as shown.
Repeat steps one and two with the three other parts
125-05, 125-06 and 125-07 to make a total of four
identical anti-aircraft guns, as shown.
Two of the four anti-aircraft gun mounts 125-05 fit
on the port side of the aft superstructure. Pegs on
the underside of the base plates fit into holes in the
superstructure deck. Press them in place but do not
use any glue.
The other two anti-aircraft guns 125-05 fit on the
starboard side of the aft superstructure. Do not use
any glue – the guns need to rotate.
04. THE FOUR TWIN AA GUNS
