KEY TO PARTS
93A Outer door panel
93B Window pane
93C Handle (x2)
93D Inner door panel
93E Bar
DP 1.7 x 4mm (x5, black)
NM 1.5 x 3mm (x4, red)
KM 1.5 x 5mm (x10, red)
EM 1.5 x 4mm (x5, silver)
FM 2.3 x 4mm (x5, black)
Before
starting to fit
the light panel,
test that the light
is working. Re-test
once it has been
fitted.
4
STAGE 93
FITTING THE DRIVER’S DOOR AND A FITTING THE DRIVER’S DOOR AND A
LIGHT FOR ONE OF THE BUS BLINDSLIGHT FOR ONE OF THE BUS BLINDS
The driver’s door is assembled and fitted. We also insert an LED
lighting panel near the position of the blind over the open platform.
93E
93D
93C
93B
93A
FM
DP NM
EM
KM
13
