4
1
2
3
1
Take the right wall framework
94A and the window pane 94I.
Fix the window pane to the inside of
the framework using four EM
screws..
2
As in previous stages, remove the excess moulding
from the manufacturing process on the sliding
window pane 94G and the window frame 94F.
3
Fit the sliding window pane 94G into the window
frame 94F so that ridges on the ends of part 94G
fit into the grooves in the frame 94F. The ‘metal’ edge
goes at the top.
4
Fit the window frame 94F (with
sliding window pane 94G) on to
the outside of the right wall framework
94A. Fix in place from the inside with
two BP screws.
94G
BP
BP
94G
94F
94F
94F
94A
94A
94I
EM
x4
19
19
AGORAMODELS ROUTEMASTER BUS
20
AGORAMODELS ROUTEMASTER BUS
