5
5
Fit the window pane 94H on the inside of
the right wall framework 94A , beneath the
sliding window. Fix in place with four OP screws.
6
7
8
7
Fit the window winder 94E into the hole in the window bar 94D.
Position the bar on the outside of the lower deck of the assembled
model (48B), across the window behind the driver’s seat. (inset).
8
Position the right wall
framework 94A against the
right side wall of the lower deck
48B so that the window bar is
enclosed. Fix the lower edge of part
94A to the edge of the chassis
frame 17A using three GM screws.
6
Identify the fixing point for the handle 94C on
the side of the right wall framework 94A, next to
the sliding window. Make sure you have the correct
orientation. Fix in place with two NM screws.
When
you are fitting
large frames with
numerous screws, it
may help to only partially
fit the screws at first and
then fully tighten once
they are all in place.
4
GM
x3
NM
x2
OP
x4
94A
48B
17A
94D
94D
48B
94E
94A
94H
94C
94A
20
20
AGORAMODELS ROUTEMASTER BUS
