9
10
11
9
Fix the top edge of the right wall
framework 94A to the edge of
the ceiling framework 73A using two
GM screws.
10
Identify the five screw
holes where the right
wall framework 94A is
attached to the side wall 48B.
Fix in place with five JP
screws.
11
Fit the long tab on the step 94B
between the front right wheel arch 33A
and the right wall framework 94A, as
indicated by the dotted lines. You may need to
loosen the screws holding part 94A in place in
order to create space to fit the tab on the step
between parts 94A and 33A. Fix the step in
place with an NM screw.
GM
JP
JP
JP
GM
48B
94A
73A
94A
94A
33A
94B
NM
21
21
AGORAMODELS ROUTEMASTER BUS
22
AGORAMODELS ROUTEMASTER BUS
