Fit the brake light 96C into the bracket 96D. This
is a push-fit connection.
STAGE 96
FITTING THE CEILING ASSEMBLY TO FITTING THE CEILING ASSEMBLY TO
THE UPPER DECKTHE UPPER DECK
The framework for the rear of the bus is assembled, together with
the number plate. We also fit the ceiling of the upper deck.
96A Rear frame
96B Rear frame
96C Brake light
96D Bracket
96E Window pane
96F Number plate frame
96G Number plate
96H Bracket
96I Tape (x12)
AP 1.7 x 3mm (x5)
JP 2.3 x 4mm (x44)
NM 1.5 x 3mm (x7)
MM 2.0 x 4mm (x4)
TM 2.0 x 5mm (x28)
WM 2.0 x 6mm (x13)
FM 2.3 x 4mm (x7)
GM 2.3 x 5mm (x13)
DP 1.7 x 4mm (x5)
(spare screws are included)
96A
96B
96C
96D
96E
96I
96I
96H
96G
96F
AP
WM
GM DP
TM
MM
FM
JP
NM
96C
96D
Before
starting assembly,
identify all the screws
and keep them to hand
in separate containers
for easy handling.
Some will be used in
future stages.
4
KEY TO PARTS SUPPLIED
