STEP BY
STEP
6
Check the fit of the two parts of the rear frame, 96A
and 96B. Fix together with three MM screws. The
inset below shows the part fixed together, with the screw
heads in recesses in part 96A.
3
4
5
6
3
Fit the light bracket 96H to the inside of the rear frame
96B with screw sockets aligned. Fix in place with two
NM screws. This bracket forms a light over the number plate.
4
Fix the number plate 96G to the number
plate frame 96F, postioning it as shown.
Fix in place with two NM screws.
5
Fit the number plate frame 96F to the rear frame 96B
beneath the brake light. The light bracket 96H fits into
the slot in the top of part 96F. Fix in place with two NM
screws.
2
2
Fit the screw sockets on the bracket 96D into the
recesses in the rear frame 96B. (Only the lower part of
the frame is shown here.) Fix in place with two AP screws.
96F
96B
96D
96B
96B
96H
AP
x2
NM
x2
NM
x2
NM
x2
MM
x3
96F
96A
96B
96G
28
28
AGORAMODELS ROUTEMASTER BUS
29
AGORAMODELS ROUTEMASTER BUS
