16
16
Working down the left-hand side of the model,
starting from the front, fix the tabs (on parts 78A
and 78C) to the corresponding fixing holes on the ceiling
(82A, 83A and 84A) using eight JP screws (the inset
shows the rear fixings).
15
15
This shows the same fitting procedure at the rear of the bus, as
described in step 14. Ensure the tabs on the far side of the bus are
also fitted in place, and the mirror housing 84C fits into the recess.
Check that
all the tabs (circled
in red) are correctly
aligned, as shown in
steps 16 and 17. Also,
ensure that the grab
poles are correctly
fitted before
proceeding.
78A
78A
78C
83A
82A
82A
84A
JP
x3
JP
x5
4
84C
32
32
AGORAMODELS ROUTEMASTER BUS
33
AGORAMODELS ROUTEMASTER BUS
