Take the window pane
96E, supplied with the
previous stage, and fit it
over the window opening
in the platform rear wall
60A. Fit it on the outside
of the wall, with the red rim
on the window pane facing
outwards. Fix in place with
four DP screws, supplied
with the previous stage.
STAGE 97
FITTING THE FIRST ROOF PANEL AND FITTING THE FIRST ROOF PANEL AND
RAIN SHIELDSRAIN SHIELDS
The rear platfrom wall is fitted, together with the front outer panel
of the roof. Rain shields are fitted above the sliding windows.
97A Rain shield (upper deck) (x6)
97B Rain shield (lower deck) (x4)
97C Roof panel
97D Front strip
NM 1.5 x 3mm (x24, red)
BP 1.5 x 3mm (x45, red)
97A
97B
97C
97D
BP
NM
60A
96E
DP
x2
DP
x2
KEY TO PARTS SUPPLIED
The rain
shields 97A, for
the upper deck,
are labelled F1. The
rainshields 97B, for the
lower deck, are labelled
F2. They are very
slightly different in
size.
