3
4
3
Fix the screw socket bracket at the
top of the platform rear wall 60A
to the lower deck ceiling 54A with a JP
screw. Note the position of the cable.
4
On the underside of the model,
anchor the platform 56A to the
screw sockets on the platform rear wall
60A with two JP screws. (The screw
sockets were fitted in place in step 2.)
2
2
Fit the platform rear wall 60A to
the back of the model assembly,
tucking the handrail 60D under the rear
wall of the upper deck (as indicated by
the curved light blue dotted line). Two
screw sockets at the base of the panel
fit into slots in the platform, as indicated
by the dark blue dotted lines. A screw
socket bracket at the top of the panel
fits beneath (light blue dotted line). Fix
the rear wall to the side stair panel 3I
with two JP screws (supplied with the
previous stage), fitting them through
the raised screw sockets, as shown.
56A
60A
56A
54A
60D
3I
60A
JP
x2
JP
JP
x2
60A
54A
37
37
AGORAMODELS ROUTEMASTER BUS
38
AGORAMODELS ROUTEMASTER BUS
