10
Take the first lower
deck rain shield 97B
and position it above the first
window behind the driver’s
door on the righthand side of
the model. Ensure the screw
holes in part 97B align with
those in the frame 94F.
10
Release the back wall panel 81A
completely by removing two JP
screws (holding it to the rear seat back
panel 66A). Guide the gable 72A into the
crevice between the rear wall 74A and the
rear seat back panel 66A. Ease the cable
down into the crevice as indicated by the
light blue arrow.
10
8
8
Fix the front strip 97D to the roof
panel 97C, using nine red NM
screws (circled in light blue). Start from
the middle and work outwards, bending
the ends around to the side of the roof
before fitting the last two screws.
9
9
Fix the roof panel 97C
in place with 12 NM red
screws (circled in light blue).
97B
94F
NM
x9
97C
97D
89A
97C
NM
x12
39
39
AGORAMODELS ROUTEMASTER BUS
40
AGORAMODELS ROUTEMASTER BUS
