KEY TO PARTS
98A Roof panel
98B Side strip
(marked A190)
98C Side strip
(marked A190M)
NM 1.5 x 3mm
(x44, red)
Some of
the screws used
in the following
instructions were
supplied with
stage 96.
4
1
1
Plug cable 72B (labelled O) and 72C
(labelled G, inset) back into the circuit board
57E. Ensure that each of the sockets on the
circuit board has a cable plugged into it, and
that that the labels on the cables match the
letters on the circuit board.
O
G
STAGE 98
ORGANISING THE WIRING AND ORGANISING THE WIRING AND
FITTING A ROOF PANELFITTING A ROOF PANEL
The second roof panel is supplied, together with finishing strips.
We also arrange the wiring neatly around the circuit board.
98C
98B
98A
NM
57E
57E
72C
72C
72B
