Agora Models RM 857 - Page 55

1
1
Fit the front window trim 100A around the
lower and side edges of the front windows of
the upper deck. Hold it in place and position strip
100C (marked A164B) down the centre of the
trim 100A. Fix both pieces in place to the front
frame 80F using three red NM screws.
80F
2
2
At the front of
the right-hand
side of the upper
deck, position strip
100D (marked
A199M) over the
edge of the trim
100A, so that the
screw holes are
aligned. Fix in place
with four red NM
screws, which go
through into screw
holes in the right
wall framework
87A.
100A
100A
100C
NM
x3
NM
x4
100D
87A
55
55
