3
3
On the front of the
left-hand side of the
upper deck, position strip
100B (marked A199) over
the edge of the front trim
100A. Fix in place with
four red NM screws, which
go into screw holes in the
left wall framework 85A.
4
4
Position the trim 100E (marked A193) across the lower edge
of the front trim 100A, so that screw holes are aligned. Fix in
place with three NM screws in the centre three holes only. The
screws go through part 100A and into the front frame 80F.
The ends of
strip 100E stick out
beyond the sides of
the bus as this stage.
Take care not to damage
the ends. They will be
fitted and fixed in
place at a later
time.
4
100A
100E
80F
100B
100A
85A
NM
x3
NM
x4
56
56
AGORAMODELS ROUTEMASTER BUS
