Agora Bismarck - STAGE 26: FORWARD PART OF THE SUPERSTRUCTURE; 01. BRIDGE DECK ACCESSORIES D1

To Next Page

To Previous Page

01. BRIDGE DECK ACCESSORIES D1 – D10

STAGE 26

FORWARD PART OF

THE SUPERSTRUCTURE

01 02

The accessories

D1–D10 are small.

It is advisable to

work on one or

two at a time:

identify them

from the photos,

then cut them

from the plastic

frame and

smooth any

rough edges.

Check the fit

before applying

the glue.

2602

2603

2601

2604

2605

2606

2601

COMPONENTS CHECKLIST

26-01: Bridge deck

26-02: Bridge accessories

(D1–D10)

26-03: Deck accessories (E1–E4)

26-04: LED holder

26-05: Cable with green light

26-06: Cable label

PB: Two 2 x 5 mm screws

Place the bridge deck 26-01 on your worktop. Cut two

rain hoods (D1 and D6) from the plastic frame 26-02

and fit them to the forward end of the port side, as

shown. Check the fit before gluing in place.

The next two parts fit on the angled side of the

forward end of the bridge deck 26-01. Fit the storage

locker D7 into the front recess, noting the alignment

of the locker. Fit the door D9 into the second recess,

so that the hinges on the door fit into the recesses on

the left-hand side.
