01. EXTENDING THE HULL

STAGE 28

HULL AND ACCESSORIES FOR THE

BRIDGE DECK

01 02

2805

2802

2801

2803

2804

2801

2701

1501

COMPONENTS CHECKLIST

28-01: Port lower hull section

28-02: Bridge deck accessoires

(H1-H8)

28-03: Port air intake cover (L)

28-04: Starboard air intake

cover (R)

28-05: Two LED covers (red

and green)

PM: Four 2 x 4 mm PM screws (1

spare)

Fit the pegs on the port lower hull section 28-01 into

the sockets in the hull section 15-01 and 27-01.

Fix the hull section 28-01 in place with three PM 2 x

4 mm screws.
