02. ACCESSORIES FOR THE FORWARD BRIDGE DECK

Stick the air intake cover 28-03 in place as shown.Place the bridge deck assembly 26-01 on your work

surface with the port side facing you. Check the fit of

the port air intake cover 28-03. Apply a little

superglue to the pegs on the edge of part 28-03.

Identify part H3, the port navigation light housing,

and cut it from the plastic frame. Cut the red LED

cover from the frame and fit it into part H3, as

indicated by the arrow.

Turn the bridge deck around and check the fit of

the starboard air intake cover 28-04. Apply a little

superglue to the pegs on the edge of part 28-04

and stick in place as shown.

Identify the fixing point for the port navigation light

housing on the bridge deck and check the fit. Apply a

little superglue on the pegs of part H3 and fix in place.

The red part of the LED cover fits into the recess in

part H3.
