Agora Bismarck - STAGE 32: HULL SECTION AND ACCESSORIES; 01. FITTING THE NEXT HULL SECTION

02
01. FITTING THE NEXT HULL SECTION
STAGE 32
HULL SECTION AND ACCESSORIES
01
PM
32-03
32-01
32-02
32-05
32-06
32-07
32-04
32-01
25-01
30-01
30-01
32-01
PM
1
2
3
5
7
6
4
COMPONENTS CHECKLIST
32-01: Upper starboard hull
section
32-02: Connector piece
32-03: Port life raft (L)
32-04: Starboard life raft(L)
32-05: Fan
32-06: Accessories (I1–I4)
32-07: Metal details (1-7)
PM: Five 2 x 4 mm PM screws
Take the upper right hull section 32-01 and position it
above the hull section 30-01 so that the screw holes
are aligned, as shown. You may need to temporarily
loosen part 25-01 when fitting in place.
Fix part 32-01 to part 30-01 with two PM screws.
