Parts List
NO. Parts Name QTY
1 CORD ARMOR 1
2 POWER SUPPLY CABLE (VDE-0.75x3Cx4.2M-H05RNF) 1
3
CABLE CLIP 2
4 PANHEAD TAPPING SCREW (M4x14) 4
5 HANDLE HALF-LEFT 1
6 PANHEAD TAPPING SCREW (M4x25) 27
7 MAIN HOUSING-LEFT 1
8 SWITCH PANEL 1
9 PANHEAD MACHINE SCREW (M4x10xP0.7) 1
10 BAYONET HOSE CONNECTOR 1
11 EMI UNIT 1
12 MAIN HOUSING-RIGHT 1
13 HANDLE HALF-RIGHT 1
14 TRUSS HEAD MACHINE SCREW (M4x10xP0.7) 3
15 EXTERNAL STAR WASHER (M4) 2
16 EXTENSION SHAFT (L800MM) 1
17 DRIVE ELECTRONICS BOARD 1
18 SUPPORT ARM-LEFT 1
19 SUPPORT ARM-RIGHT 1
20 PANHEAD TAPPING SCREW(M5x16) 2
21 BUSHING (Ø5xØ7x7) 4
22 TRUSS HEAD MACHINE SCREW (M5x12xP0.8) 2
23 PIVOT BRACKET 1
24 O-RING (Ø7x2) 2
25 MOTOR END CASTING 1
26 FAN 1
27 MOTOR HOUSING 1
28 BALL BEARING (608) 2
29 STATOR (60x34.8x15) 1
30 BUSHING (Ø6xØ10x8) 3
31 ROTOR 1
32 EXTERNAL CIRCLIP (S10) 1
33 OUTPUT GEAR (M0.8x42T)/(M0.8x39T) 1
34 EXTERNAL CIRCLIP (S-15) 1
35 GEAR PLATE 1
36 INTERNAL CIRCLIP (R-32) 1
37 BALL BEARING (6002) 1
38 INPUT GEAR (M0.7x30T) 1
39 INPUT SHAFT (M0.8x14T)/ (M0.8x17T) 1
40 PARALLEL KEY (3x3x6) 1
41 GEAR HOUSING 1
42 OIL SEAL (Ø17xØ28x5) 1
43 SPINDLE 1
44 PARALLEL KEY (4x4x6) 1
45 CONNECTION CABLE 1
46 VACCUM HOSE 1
47 SPRING (Ø1xØ30xØ32x278Lx38T) 1
48 PLASTIC CLIP 1
49 SPRING (Ø0.7x6Tx20L) 4
50 SANDING COVER BASE 1
51 EXTERNAL CIRCLIP (S-38) 1
52 SANDING PLATE COVER 1
53 TORSION SPRING 1
54 HALF-MOON DOOR 1
55 PIVOT PIN (Ø2x48) 1
56 TRUSS HEAD TAPPING SCREW (M4x6) 8
57 SANDING PLATE BASE 1
58 VELCRO SPONGE PAD (9’) 1
59 HEX KEY (M6) 1
60 CARRY BAG 1
61 TRUSS HEAD MACHINE SCREW (M4x6xP0.7) 1
62 VACUUM EXTENSION HOSE (4M) 1
