BE-AGLxxxF USER MANUAL 19
1-5
REF SYSTEM NO. PART NO. DESCRIPTION QTY
1 802710100 EFAGL125.030 (L=400) Support leg
2
2 703140001 MFP120.00.101 Seal cap
2
3 800920101 EF100.00.111A Square cotter 2
4 802710045 EFAGL125.017 Rear swing arm 1
5 511050221 SF-2-30X34X30 Self-lubricating bear-ing 4
6 509010009 GB1152-M10X1 Oil cup 5
7 501011098 GB5783-M8X16 Screw bolt 2
8-1 810240073 EFAGL165A-1000-00 Side-sway cylinder 1
8-2 810420012 EFAGL105A-0300-00 (105) Side-sway cyl-inder 1
9 705190066 1CM-18-16WD M18X1.5-M16X1.5 Transit joint 2
10 511050222 SF-2-65X70X40 Self-lubricating bear-ing 2
11 802710094 EFAGL125.109 Long pin 2
12 501014929 GB5785-M24X1.5X90 Half-thread bolt 1
13 710240015 EFAGL165A-0000-04 Pusher 1
14 810240096 EFAGL165A-1900-00 Puller 1
15 501010829 GB5782-M24X80 Half-thread bolt 1
16 503010769 DIN985-M24 Thin nut 7
17 511050220 SF-2-30X34X40 Self-lubricating bear-ing 4
18 810240061 EFAGL165A-0300-00 Front swing arm 1
19 501011111 GB5783-M10X20 Screw bolt 4
20 506030036 GB93-10 Spring washer 4
21 506010056 GB97.1-10 Flat gasket 4
22 800920138 EF100.00.019A Upper pull rod pin 1
23 809820065 AGFR245-2500-00 Fixing sleeve 4
24 810250001 EFAGL165B-0100-00 Hanging weldment 1
25 802710093 EFAGL125.108 Step pin 1
26 810240069 EFAGL165A-0600-00 Deflection cylinder 1
27 802710089 EFAGL125.103-MH Lockpin rivet 1
28 509010007 GB1152-M6 Oil cup 2
29 506030035 GB93-8 Spring washer 2
30 501011233 GB5783-M24X65 Screw bolt 1
31 802710092 EFAGL125.107 Short pin 1
32 810240091 EFAGL165A-1800-00 Rear swing arm seat 1
33 700250036 1CB-18-06WD M18X1.5-G3/8 joint 2
34 710240030 EFAGL165A-0000-09 Pressing ring 1
35 503020346 GB812-M24X1.5 Round nut 1
36 802710090 EFAGL125.104-MH Long lock pin rivet 1
