BE-FMxRDG
Rear Discharge
Finish Mower
Operations & Parts Manual
• BE-FM48RDG
• BE-FM60RDG
• BE-FM72RDG
For Models:
Purchase Date
Dealer
Model No. Serial No.

Questions and Answers

  • A
    Andrea GutierrezAug 19, 2025
    How to fix streaking when using my AGRI EASE BE-FM RDG?
    • G
      grahamjessicaAug 19, 2025
      Streaking during mowing with your AGRI EASE Lawn Mower can occur due to several reasons. It might be caused by slow blade tip speed, so ensure you operate the PTO at 540 RPM. Other potential causes include worn or dull blades, which require replacement or sharpening. If the blades can't cut the grass pressed down by the tractor's tire path, reduce the tractor's ground speed while maintaining the PTO speed. Mowing too fast or wet conditions can also lead to streaking, so slow down and allow the grass to dry, respectively. Also, a loose or glazed drive belt needs tightening or replacement, and a loose blade on the spindle should be tightened securely.
  • A
    Allen NguyenAug 21, 2025
    What to do if the belt is slipping on my AGRI EASE BE-FM RDG?
    • J
      James HarrisAug 21, 2025
      If the belt is slipping on your AGRI EASE Lawn Mower, it could be due to several factors. The belt may be loose, glazed, or have oil on it, requiring tightening, application of belt dressing, cleaning, or replacement. The mower might be overloading because the grass is too tall or heavy; in this case, slow the tractor's ground speed while maintaining 540 RPM PTO speed, cut the grass twice, raise the mower for the first pass, and lower it for the second pass, cutting at a 90-degree angle to the first. Also, check the belt for free travel in the sheaves and remove any debris or foreign material under the mower deck and spindles.
  • C
    Catherine JonesAug 23, 2025
    Why does grass discharge unevenly from my AGRI EASE BE-FM RDG?
    • M
      Mary RasmussenAug 23, 2025
      Uneven grass discharge or bunching from your AGRI EASE Lawn Mower can happen if the grass is too high, coarse, or wet. To resolve this, slow the tractor's ground speed while maintaining 540 RPM PTO speed. For high or coarse grass, raise the mower for the first pass, lower it to the desired height for the second pass, and cut at 90 degrees to the first pass. Ensure the rear of the mower is high enough for grass discharge without causing streaking. If the grass is wet, allow it to dry before mowing and consider cutting at a lower height. Also, make sure that the belt is tightened or replaced.
  • J
    julia76Aug 26, 2025
    What causes heavy vibration in my AGRI EASE BE-FM RDG Lawn Mower?
    • B
      Beth GeorgeAug 26, 2025
      Heavy vibration in your AGRI EASE Lawn Mower can be caused by several issues. The blade speed might be too fast, so do not exceed 540 RPM PTO speed. A broken, bent, worn, or unbalanced blade can also cause vibration, requiring replacement or grinding. Additionally, check for a bent or broken sheave, which should be replaced, or debris caught on the blade, which should be cleaned off.
  • A
    Amanda HernandezAug 27, 2025
    Why does my AGRI EASE BE-FM RDG Lawn Mower require excessive power?
    • M
      Michael DukeAug 27, 2025
      Your AGRI EASE Lawn Mower requiring excessive power can stem from several factors. If you're advancing into the grass too rapidly, reduce your forward travel speed. Hitting the ground can also cause this issue, so raise the mower and reset the wheels. Other potential causes include worn or dull blades (sharpen or replace them), using a tractor that isn't large enough (use a larger horsepower tractor), wet grass (allow it to dry), or grass that's too tall and heavy (slow ground speed and make two passes, raising the mower for the first pass and lowering it for the second).
  • S
    Sara NguyenAug 30, 2025
    How to prevent blades from wearing too fast on my AGRI EASE Lawn Mower?
    • N
      Nathan McdonaldAug 30, 2025
      If the blades on your AGRI EASE Lawn Mower are wearing too fast, it could be due to cutting in sandy or rocky conditions, or the blades hitting the ground. To mitigate this, increase the cutting height. If rocks are the issue, remove them from the area.
  • L
    Luis GomezSep 1, 2025
    Why is the gearbox overheating on my AGRI EASE Lawn Mower?
    • L
      Linda DaltonSep 1, 2025
      If your AGRI EASE Lawn Mower's gearbox is overheating, it may be low on lubricant, using an improper type of lubricant, or have excessive trash build-up around it. Ensure the lubricant is filled to the proper level, replace it with the proper type if needed, and remove any trash from around the gearbox.
  • L
    lwallerSep 3, 2025
    What to do if the belt is damaged on my AGRI EASE BE-FM RDG?
    • B
      Brianna Garrison DVMSep 3, 2025
      A damaged belt on your AGRI EASE Lawn Mower, whether from rollover, high shock loads, or installation damage, should be replaced with the correct specified belt.
  • S
    Stephen BriggsSep 5, 2025
    Why is the blade scraping the ground on my AGRI EASE BE-FM RDG?
    • J
      Jeffrey WilliamsSep 5, 2025
      If the blade of your AGRI EASE Lawn Mower is scraping the ground, it could be because the mower is set too low, the field is ridged, or the field is too wet. Raise the mower and reset the wheels. If the field is ridged, try cutting at a different angle. If the field is too wet, wait until it dries before mowing.
  • J
    Jeffrey BrockSep 7, 2025
    What causes belt breakage on my AGRI EASE Lawn Mower?
    • J
      Jeremiah HenrySep 7, 2025
      Belt breakage on your AGRI EASE Lawn Mower is often due to high shock loads. To prevent this, avoid hitting the ground and large obstructions with the mower. Also, check the sheave for proper alignment and foreign material, and ensure proper belt tension.

Summary

TO THE CUSTOMER

SAFETY SIGNS AND GUIDELINES

Equipment Safety Guidelines

Essential safety rules for operation and operator responsibilities.

How To Install Safety Signs

Instructions for applying safety decals to the equipment.

SAFETY TRAINING

PREPARATION FOR OPERATION

Pre-Operation Safety Checks

Covers pre-operation checks, PPE, noise, ROPS, and area clearing.

OPERATIONAL AND STORAGE SAFETY

Operational, Starting, Stopping, and Storage Safety

Details safe operating practices, starting, stopping, and storage procedures.

MAINTENANCE SAFETY

TRANSPORT SAFETY

SAFETY SIGN LOCATIONS

DETAILED SAFETY SIGN DESCRIPTIONS

Hazard Warnings and General Safety

Specific warnings for hazards and general safety precautions.

FINISHING MOWER ASSEMBLY INSTRUCTIONS

OPERATING INSTRUCTIONS

Tractor Preparation

Guidance on preparing the tractor for mower attachment and operation.

Driveline Attachment and Height Adjustment

Instructions for connecting the driveline and adjusting cutting height.

Tractor Requirements

Specifies tractor compatibility and necessary features for safe mower use.

MOWER OPERATION PROCEDURES

Starting, Stopping, and Cutting

Procedures for starting, stopping the mower, and cutting grass.

Cutting Speed and Tips

Recommendations for optimal cutting speed and techniques for a clean cut.

DETACHING AND TRANSPORT PREPARATION

Detaching and Storing

Steps for safely detaching and preparing the mower for storage.

Before Operating or Transporting

Pre-operation and pre-transport checks, including SMV display.

MAINTENANCE INSTRUCTIONS

Lubrication Overview and Fittings

Information on lubrication points and recommended grease types.

GEARBOX AND DRIVELINE LUBRICATION

BLADE AND SPINDLE MAINTENANCE

Blade Spindle Lubrication

Procedures for lubricating blade spindles.

Blade Servicing and Installation

Guidelines for servicing, removing, and installing mower blades.

BLADE SHARPENING AND BELT ADJUSTMENT

STORAGE PROCEDURES

TROUBLESHOOTING: CUTTING AND BELT ISSUES

Streaking, Discharge, and Belt Problems

Solutions for streaking, uneven grass discharge, and belt issues.

TROUBLESHOOTING: VIBRATION AND BELT ISSUES

Heavy Vibration and Belt Slipping;Rollover

Troubleshooting steps for heavy vibration and belt slipping/rollover.

TROUBLESHOOTING: GEARBOX AND BELT ISSUES

Belt Breakage, Blade Scraping, Gearbox Issues

Solutions for belt breakage, blade scraping, and gearbox problems.

TROUBLESHOOTING: POWER AND MOVEMENT ISSUES

Gearbox Noise, Blade Wear, and Power Issues

Addresses gearbox noise, fast blade wear, and excessive power requirements.

FINISHING MOWER PARTS BREAKDOWN

FINISHING MOWER DIAGRAM
