Agri-Fab 175 - Page 5

5
11. Turnthespreaderuprightonitswheels.
12. Attach the hopper strap to the front and rear of the
hopperusingtwo1/4"x1"hexbolts,5/16"atwashers,
nylonwashersand1/4"nylocknuts.Seegure5.
FIGURE 5
9. Assembletheshortspacertubeanda1-5/8"atwasher
ontotheendoftheaxlethathasthelargehole.See
gure4.
10. Placethedrivewheel(boltholethroughhub)ontothe
axlesothattheairvalveistotheoutside.Securethe
wheeltotheaxlewitha1/4"x2"hexboltanda1/4"
nylocknut.Seegure4.
FIGURE 4
15. Assembletheowcontrollink(endwithsmallhole)to
theowcontrolarmusinga1/4"x1"hexbolt,anylon
washeranda1/4"nylocknut.Tighten thenutuntilthe
ow control link pivots with a slight resistance. See
gure7.
FIGURE 6
3/8" x 1-1/4"
HEX BOLT
3/8" LOCK
WASHER
3/8" NYLOCK NUT
HITCH PIN
HAIR COTTER PIN
FLOW CONTROL
LINK
FLOW
CONTROL
ARM
1/4" NYLOCK NUT
1/4" x 1"
HEX BOLT
SMALLEST
HOLE
NYLON
WASHER
13. Assemblethehitchbrackettothetopofthehitchtube
usingtwo3/8"x1-1/4"hexboltsand3/8"nylocknuts.
Seegure6.
14. Assemblethehitchpinthroughthehitchbracketand
thehitchtubeandsecurewiththehaircotterpin.See
gure6.
HOPPER STRAP
NYLON WASHER
5/16" FLAT WASHER
1/4" x 1" HEX BOLT
1/4" NYLOCK NUT
FIGURE 7
1/4" NYLOCK NUT
1/4" x 2"
HEX BOLT
DRIVE WHEEL
AIR VALVE
SHORT SPACER TUBE
1-5/8" DIA.
FLAT WASHER
