Agri-Fab 175 - Page 6

6
18. Placea5/16"atwasherontotheendoftheowcontrol
rod.Inserttheendoftherodthroughtheslotintheow
controlmountingbracketandthroughtheholeinthe
owcontrollink.Securewitha3/32"x3/4"cotterpin.
Seegure9.
FIGURE 9
19. Hookthefreeendoftheowcontrolrodthroughthe
holeintheslidegatebracketlocatednearthebottom
ofthehopper.Seegure10.
FIGURE 10
20. Assembletheowcontrolmountingbrackettothehitch
tubeusingtwo1/4"x2"hexbolts,six5/16"atwashers
andtwo1/4"hexlocknutsasshowningure11. Do
not tighten at this time.
FIGURE 11
FLOW
CONTROL
ROD
FLOW
CONTROL
LINK
3/32"
COTTER
PIN
5/16" FLAT
WASHER
SLOT
16. Assemble the ow control arm to the ow control
mountingbracketusinga1/4"x1"hexbolt,twonylon
washersand a1/4"nylock nutasshown ingure8.
Tighten thenutuntiltheowcontrolarmpivotswitha
slightresistance.
17. Assemblethevinylgrip.Seegure8.
FIGURE 8
1/4" x 1"
HEX BOLT
1/4" NYLOCK
NUT
FLOW CONTROL
MOUNTING
BRACKET
FLOW
CONTROL
ARM
(2) NYLON
WASHERS
VINYL GRIP
FLOW CONTROL
MOUNTING BRACKET
1/4" x 2"
HEX BOLT
1/4" HEX
LOCK NUT
5/16" FLAT
WASHER
5/16" FLAT
WASHER
