Agri-Fab 45-0366 - Hardware and Carton Contents; Carton Contents

3
REF. QTY. DESCRIPTION
REF. QTY. DESCRIPTION
REF. QTY. DESCRIPTION
A 24 Hex Bolt, 3/8" x 1"
A 24 Hex Bolt, 3/8" x 1"
B 24 Nylock Hex Nut, 3/8"
B 24 Nylock Hex Nut, 3/8"
B 24 Nylock Hex Nut, 3/8"
C 1 Slotted Hex Nut, 1"
C 1 Slotted Hex Nut, 1"
C 1 Slotted Hex Nut, 1"
D 1 Haircotter Pin
D 1 Haircotter Pin
D 1 Haircotter Pin
E 1 Pivot Pin
E 1 Pivot Pin
E 1 Pivot Pin
F 1 Cotter Pin
F 1 Cotter Pin
F 1 Cotter Pin
CARTON CONTENTS
1. Hitch Assembly
2. Rake Pivot Assembly
3. Rake Tines (24)
A C
B D E F
SHOWN FULL SIZE
1
2
3
HARDWARE PACKAGE CONTENTS
