45-0521 REPAIR PARTS LIST
REF QTY PART NO DESCRIPTION
1 2 27425 Drawbar Bracket
2 1 43038 Pivot Lock Pin 3/8" x 1-1/2"
3 2 42646 Hopper Support Rod
4 1 45323 Bag Frame Tube
5 2 45324 Rear Hopper Tube
6 1 23014 Hitch Bracket
7 1 24192 Hitch Bracket (Straight)
8 1 27421 Drawbar
9 1 68868 Height Adjustment Tube
10 1 45325 Hopper Bag
11 1 43737 Hopper Rope
12 2 27424 Bag Arm
13 2 40897 Lower Hopper Tube
14 2 42539 Upper Hopper Tube
15 5 HA23636 Clevis Pin, 3/8 x 2-1/4"
16 4 45088 Wheel Bearing
17 13 43055 Hair Pin, 3/32 x 1.8"
18 6 48365 Clevis Pin, 1/4 x 1.11"
19 2 42210 Nylock Jam Nut, 3/8"
20 2 712-3008 Jam Nut, 3/8"
21 2 43343 Hair Cotter Pin, 3/32 x 2-5/16"
22 2 48366 Clevis Pin, 3/8 x 1/2"
23 4 43661 Hex Bolt, 1/4-20 x 1"
24 8 23581 Brush Retainer (SIngle)
25 5 44292 Bolt, Hex 5/16-18 x 2-1/2"
26 5 47810 Nut, Nylock 5/16-18
27 4 23580 Brush Retainer (Double)
28 2 27426 Pivot Rod Support Bracket
29 2 26484 Pivot Rod Retainer
REF QTY PART NO DESCRIPTION
30 12 47189 Nylock Nut, 1/4"
31 8 43012 Hex Bolt, 1/4-20 x 3/4"
32 2 47605 Washer, .411" x 1" x .03"
33 1 23353 Hitch Pin
34 2 23368 Spacer
35 2 41036 Compression Spring
36 2 43432 Hex Bolt, 3/8-16 x 2-1/2"
37 1 68855 Sweeper Housing
38 2 28366 Dust Cover
39 4 HA24433 Pop Rivet
40 2 40001 Shim Washer
41 1 48651 Pinion Gear (LH)
42 1 48652 Pinion Gear (RH)
43 2 47046 Dowel Pin, 1/4 x 3/4"
44 2 42094 Retaining Ring
45 2 67407 Bearing Assembly
46 2 46454 Plastic Plug
47 4 1540-31 Washer, 1-1/4"
48 2 42093 Washer, .598"
49 1 28378 Brush Shaft
50 2 26538 Step Spacer
51 2 141 Washer, 1-1/4"
52 2 1038 Nylock Jam Nut, 3/8"
53 2 2674-32 Hub Cap
54 2 710-1273 Hex Bolt, 3/8-24 x 2-3/4"
55 2 44985 Wheel
56 4 46780 Brush
1 45319 Owner's Manual
