存放
Storage
6.2.2.14 前轮润滑油加注
Lub oil filling of the front wheel
6.2.2.15 前驱动桥主销的润滑
front drive axle central swivel pin tube
6.2.2.16 传动系的保养
Transmission system maintenance
6.2.2.17 提升器的保养
Lifter Maintenance
将拖拉机停放在水平地面上，将提升臂下降至最低位置，发动机熄火，拧下提升器上盖上的油
尺，检查油面高度，如果低于下刻线应补充加油至上下刻线之间。更换液压油时应将螺塞卸掉放尽脏油，
清洗干净后，按要求加注新液压油。
Parking the tractor in flat ground, descending lift arm to the minimum location, extinguishing engine, taking
out the lifter cover dip stick, check the oil surface height. If the surface is under the lower mark, filling the oil
till it locates between upper and lower marks. In hydraulic oil replacement, the plug should be removed to
release dirty oil, and new oil be filled in as required after cleaning it.
检查油面时，要将拖拉机停放在水平地面上，将发动机熄火，将位于主变速杆右侧的油尺拧出，擦拭干
净，然后插入油尺，如果油面低于油尺的下刻线，应补加传动油至油尺上下刻线之间(应在加机油 5 分
钟后测量)。更换润滑油时，卸掉位于传动箱底部的放油螺塞，放尽脏油，并用柴油清洗，然后把放油
螺塞拧紧，加注新机油。
When checking oil surface, parking the tractor in a flat ground, extinguishing the engine, take out the dip stick
of the lifter front part and rear axle, wipe up, then insert the dip stick. If the oil surface lower than the lower
mark, filing the lub oil till the oil surface locates between the upper and lower marks ( measure filling lub oil
after 5min) When changing lube oil. the drain plug l in the transfer box should be removed, to completely
drain used oil, then put oil drain plug to tight, and fill fresh lube oil.
沭河 SH90 系列拖拉机前驱动桥中间摆轴两端各有 1 个油杯，要定期加注润滑脂，一般每工作 400h 加
注一次。There is an oil cup at each end of the central pendulum shaft of the front drive axle. It is necessary to
periodically add grease in these cups, generally every 400h a time.
沭河 SH90 系列拖拉机前轮的润滑在前轮的内侧轮毂油杯处加注润滑脂。
Fill lubricating grease in the oil cup of the inner hub of the front wheel.
图 6-3 放油螺塞
Fig.6-3 Oil drain plug
图 6-4 加注孔螺塞
Fig.6-4 Filling hole plug
